5x12" Double Frame Port

505C Double Frame fully cast Port Extremely rigid construction actually strengthens the deck Alloy is stronger than Stainless Steel , Lighter than Aluminum and will NEVER Corrode Standard Screen and Outer Trim Ring Included Opening dimension 5" x 12" (12.7 x 30.5 cm) Flange dimension 8" x 14 1/2" (20.3 x 36.8) Cutout dimension 5 5/8" x 12 5/8" (14.3 x 32.1 cm) Spigot length 1 1/4" (3.1 cm) Fits hull thickness from 1/4" to 2 1/4".

The 505 port is designed for offshore conditions.

Features of the 505 double frame port:

• Two year warranty.
• Fits wall thickness from ¼" to 2¼". Wall can have slight curve since outer ring will bend.
• All construction materials are of non-corroding material.
• Standard clear anodized finish
• Screen included.
• Self draining.
• Watertight and extremely durable.
• 3/8" acrylic glazing.
• Predrilled for easy installation.
• Opening section is self supporting.

Options

• 2¼" (5.7 cm) spigot ring available for all models except 505B
